SMA Series(DO-214AC/SMA/SOD106)

Name: GS2WA
Brand: Shanghai Leiditech上海雷卯电子科技有限公司是专业的静电保护元件厂家,TVS二极管供应商;专业提供防雷防静电方案,电磁兼容EMC免费测试等服务,品质保证,库存充足,型号齐全,值得信赖,如有采购静电保护元件,TVS二极管需求,请联系雷卯,24小时服务热线:021-50828806.
SKU: 09854
Availability: InStock
Rating: 5 (1 reviews)

Inicio > Diodo de supresión de voltaje transitorio TVS > SMA Series(DO-214AC/SMA/SOD106)

Características/aplicaciones Demostración de modelos similares Buscar materiales alternativos

Características/aplicaciones

Features

The plastic package carries Underwriters Laboratory

Flammability Classification 94V-0

Idea for printed circuit board

Glass passivated junction chip

Low reverse leakage

High forward surge current capability

High temperature soldering guaranteed

260°c/10 seconds at terminals

Mechanical Data

Case:Molded plastic body

Terminals:Solder plated, solderable per MIL-STD-750,Method 2026

Polarity:Polarity symbol marking on body

Mounting Position: Any

Weight:0.0023 ounce,0.07 grams

Demostración de modelos similares

SMAJ3.3A SMAJ3.3CA 400 3.3 100 4.20 6.10 1 7.3 50.0 SMA

SMAJ5.0A SMAJ5.0CA 400 5.0 100 6.40 7.00 10 9.2 43.5 SMA

SMAJ6.0A SMAJ6.0CA 400 6.0 100 6.67 7.37 10 10.3 38.8 SMA

SMAJ6.5A SMAJ6.5CA 400 6.5 50 7.22 7.98 10 11.2 35.7 SMA

SMAJ7.0A SMAJ7.0CA 400 7.0 50 7.78 8.60 10 12.0 33.3 SMA

SMAJ7.5A SMAJ7.5CA 400 7.5 50 8.33 9.21 1 12.9 31.0 SMA

SMAJ8.0A SMAJ8.0CA 400 8.0 20 8.89 9.83 1 13.6 29.4 SMA

SMAJ8.5A SMAJ8.5CA 400 8.5 10 9.44 10.40 1 14.4 27.8 SMA

SMAJ9.0A SMAJ9.0CA 400 9.0 5 10.00 11.10 1 15.4 26.0 SMA

SMAJ10A SMAJ10CA 400 10.0 2 11.10 12.30 1 17.0 23.5 SMA

SMAJ11A SMAJ11CA 400 11.0 1 12.20 13.50 1 18.2 22.0 SMA

SMAJ12A SMAJ12CA 400 12.0 1 13.30 14.70 1 19.9 20.1 SMA

SMAJ13A SMAJ13CA 400 13.0 1 14.40 15.90 1 21.5 18.6 SMA

SMAJ14A SMAJ14CA 400 14.0 1 15.60 17.20 1 23.2 17.3 SMA

SMAJ15A SMAJ15CA 400 15.0 1 16.70 18.50 1 24.4 16.4 SMA

SMAJ16A SMAJ16CA 400 16.0 1 17.80 19.70 1 26.0 15.4 SMA

SMAJ17A SMAJ17CA 400 17.0 1 18.90 20.90 1 27.6 14.5 SMA

SMAJ18A SMAJ18CA 400 18.0 1 20.00 22.10 1 29.2 13.7 SMA

SMAJ20A SMAJ20CA 400 20.0 1 22.20 24.50 1 32.4 12.4 SMA

SMAJ22A SMAJ22CA 400 22.0 1 24.40 26.90 1 35.5 11.3 SMA

SMAJ24A SMAJ24CA 400 24.0 1 26.70 29.50 1 38.9 10.3 SMA

S-SMAJ24A S-SMAJ24CA 400 24.0 1 26.70 29.50 1 38.9 10.3 SMA 车用

SMAJ26A SMAJ26CA 400 26.0 1 28.90 31.90 1 42.1 9.5 SMA

SMAJ28A SMAJ28CA 400 28.0 1 31.10 34.40 1 45.4 8.8 SMA

SMAJ30A SMAJ30CA 400 30.0 1 33.30 36.80 1 48.4 8.3 SMA

SMAJ33A SMAJ33CA 400 33.0 1 36.70 40.60 1 53.3 7.5 SMA

S-SMAJ33A S-SMAJ33CA 400 33.0 1 36.70 40.60 1 53.3 7.5 SMA 车用

SMAJ36A SMAJ36CA 400 36.0 1 40.00 44.20 1 58.1 6.9 SMA

S-SMAJ36A S-SMAJ36CA 400 36.0 1 40.00 44.20 1 58.1 6.9 SMA 车用

SMAJ40A SMAJ40CA 400 40.0 1 44.40 49.10 1 64.5 6.2 SMA

SMAJ43A SMAJ43CA 400 43.0 1 47.80 52.80 1 69.4 5.8 SMA

SMAJ45A SMAJ45CA 400 45.0 1 50.00 55.30 1 72.7 5.5 SMA

SMAJ48A SMAJ48CA 400 48.0 1 53.30 58.90 1 77.4 5.2 SMA

SMAJ51A SMAJ51CA 400 51.0 1 56.70 62.70 1 82.4 4.9 SMA

SMAJ54A SMAJ54CA 400 54.0 1 60.00 66.30 1 87.1 4.6 SMA

SMAJ58A SMAJ58CA 400 58.0 1 64.40 71.20 1 93.6 4.3 SMA

SMAJ60A SMAJ60CA 400 60.0 1 66.70 73.70 1 96.8 4.1 SMA

SMAJ64A SMAJ64CA 400 64.0 1 71.10 78.60 1 103.0 3.9 SMA

SMAJ70A SMAJ70CA 400 70.0 1 77.80 86.00 1 113.0 3.6 SMA

SMAJ75A SMAJ75CA 400 75.0 1 83.30 92.10 1 121.0 3.3 SMA

SMAJ78A SMAJ78CA 400 78.0 1 86.70 95.80 1 126.0 3.2 SMA

SMAJ85A SMAJ85CA 400 85.0 1 94.40 104.00 1 137.0 2.9 SMA

SMAJ90A SMAJ90CA 400 90.0 1 100.00 111.00 1 146.0 2.8 SMA

SMAJ100A SMAJ100CA 400 100.0 1 111.00 123.00 1 162.0 2.5 SMA

SMAJ110A SMAJ110CA 400 110.0 1 122.00 135.00 1 177.0 2.3 SMA

SMAJ120A SMAJ120CA 400 120.0 1 133.00 147.00 1 193.0 2.1 SMA

SMAJ130A SMAJ130CA 400 130.0 1 144.00 159.00 1 209.0 1.9 SMA

SMAJ150A SMAJ150CA 400 150.0 1 167.00 185.00 1 243.0 1.7 SMA

SMAJ160A SMAJ160CA 400 160.0 1 178.00 197.00 1 259.0 1.6 SMA

SMAJ170A SMAJ170CA 400 170.0 1 189.00 209.00 1 275.0 1.5 SMA

SMAJ180A SMAJ180CA 400 180.0 1 201.00 222.00 1 292.0 1.4 SMA

SMAJ200A SMAJ200CA 400 200.0 1 224.00 247.00 1 324.0 1.3 SMA

SMAJ220A SMAJ220CA 400 220.0 1 246.00 272.00 1 356.0 1.1 SMA

SMAJ250A SMAJ250CA 400 250.0 1 279.00 309.00 1 405.0 1.0 SMA

SMAJ300A SMAJ300CA 400 300.0 1 335.00 371.00 1 486.0 0.8 SMA

SMAJ350A SMAJ350CA 400 350.0 1 391.00 432.00 1 567.0 0.7 SMA

SMAJ400A SMAJ400CA 400 400.0 1 447.00 494.00 1 648.0 0.6 SMA

SMAJ440A SMAJ440CA 400 440.0 1 492.00 543.00 1 713.0 0.6 SMA

6AJ5.0A 6AJ5.0CA 600 5.0 100 6.40 7.00 10 9.2 65.2 SMA

6AJ6.0A 6AJ6.0CA 600 6.0 100 6.67 7.37 10 10.3 58.3 SMA

6AJ6.5A 6AJ6.5CA 600 6.5 50 7.22 7.98 10 11.2 53.6 SMA

6AJ7.0A 6AJ7.0CA 600 7.0 50 7.78 8.60 10 12.0 50.0 SMA

6AJ7.5A 6AJ7.5CA 600 7.5 50 8.33 9.21 1 12.9 46.5 SMA

6AJ8.0A 6AJ8.0CA 600 8.0 20 8.89 9.83 1 13.6 44.1 SMA

6AJ8.5A 6AJ8.5CA 600 8.5 10 9.44 10.40 1 14.4 41.7 SMA

6AJ9.0A 6AJ9.0CA 600 9.0 5 10.00 11.10 1 15.4 39.0 SMA

6AJ10A 6AJ10CA 600 10.0 2 11.00 12.30 1 17.0 35.3 SMA

6AJ11A 6AJ11CA 600 11.0 1 12.20 13.50 1 18.2 33.0 SMA

6AJ12A 6AJ12CA 600 12.0 1 13.30 14.70 1 19.9 30.2 SMA

6AJ13A 6AJ13CA 600 13.0 1 14.40 15.90 1 21.5 27.9 SMA

6AJ14A 6AJ14CA 600 14.0 1 15.60 17.20 1 23.2 25.9 SMA

6AJ15A 6AJ15CA 600 15.0 1 16.70 18.50 1 24.4 24.6 SMA

6AJ16A 6AJ16CA 600 16.0 1 17.80 19.70 1 26.0 23.1 SMA

6AJ17A 6AJ17CA 600 17.0 1 18.90 20.90 1 27.6 21.8 SMA

6AJ18A 6AJ18CA 600 18.0 1 20.00 22.10 1 29.2 20.6 SMA

6AJ20A 6AJ20CA 600 20.0 1 22.20 24.50 1 32.4 18.6 SMA

6AJ22A 6AJ22CA 600 22.0 1 24.40 26.90 1 35.5 16.9 SMA

6AJ24A 6AJ24CA 600 24.0 1 26.70 29.50 1 38.9 15.4 SMA

S-6AJ24A S-6AJ24CA 600 24.0 1 26.70 29.50 1 38.9 15.4 SMA 车用

6AJ26A 6AJ26CA 600 26.0 1 28.90 31.90 1 42.1 14.3 SMA

6AJ28A 6AJ28CA 600 28.0 1 31.10 34.40 1 45.4 13.2 SMA

6AJ30A 6AJ30CA 600 30.0 1 33.30 36.80 1 48.4 12.4 SMA

6AJ33A 6AJ33CA 600 33.0 1 36.70 40.60 1 53.3 11.3 SMA

S-6AJ33A S-6AJ33CA 600 33.0 1 36.70 40.60 1 53.3 11.3 SMA 车用

6AJ36A 6AJ36CA 600 36.0 1 40.00 44.20 1 58.1 10.4 SMA

S-6AJ36A S-6AJ36CA 600 36.0 1 40.00 44.20 1 58.1 10.4 SMA 车用

6AJ40A 6AJ40CA 600 40.0 1 44.40 49.10 1 64.5 9.3 SMA

6AJ43A 6AJ43CA 600 43.0 1 47.80 52.80 1 69.4 8.7 SMA

6AJ45A 6AJ45CA 600 45.0 1 50.00 55.30 1 72.7 8.3 SMA

6AJ48A 6AJ48CA 600 48.0 1 53.30 58.90 1 77.4 7.8 SMA

6AJ51A 6AJ51CA 600 51.0 1 56.70 62.70 1 82.4 7.3 SMA

6AJ54A 6AJ54CA 600 54.0 1 60.00 66.30 1 87.1 6.9 SMA

6AJ58A 6AJ58CA 600 58.0 1 64.40 71.20 1 93.6 6.4 SMA

6AJ60A 6AJ60CA 600 60.0 1 66.70 73.70 1 96.8 6.2 SMA

S-6AJ60A S-6AJ60CA 600 60.0 1 66.70 73.70 1 96.8 6.2 SMA 车用

6AJ64A 6AJ64CA 600 64.0 1 71.10 78.60 1 103.0 5.8 SMA

6AJ70A 6AJ70CA 600 70.0 1 77.80 86.00 1 113.0 5.3 SMA

6AJ75A 6AJ75CA 600 75.0 1 83.30 92.10 1 121.0 5.0 SMA

6AJ78A 6AJ78CA 600 78.0 1 86.70 95.80 1 126.0 4.8 SMA

6AJ85A 6AJ85CA 600 85.0 1 94.40 104.00 1 137.0 4.4 SMA

6AJ90A 6AJ90CA 600 90.0 1 100.00 111.00 1 146.0 4.1 SMA

6AJ100A 6AJ100CA 600 100.0 1 111.00 123.00 1 162.0 3.7 SMA

6AJ110A 6AJ110CA 600 110.0 1 122.00 135.00 1 177.0 3.4 SMA

6AJ120A 6AJ120CA 600 120.0 1 133.00 147.00 1 193.0 3.1 SMA

6AJ130A 6AJ130CA 600 130.0 1 144.00 159.00 1 209.0 2.9 SMA

6AJ150A 6AJ150CA 600 150.0 1 167.00 185.00 1 243.0 2.5 SMA

6AJ160A 6AJ160CA 600 160.0 1 178.00 197.00 1 259.0 2.3 SMA

6AJ170A 6AJ170CA 600 170.0 1 189.00 209.00 1 275.0 2.2 SMA

6AJ180A 6AJ180CA 600 180.0 1 201.00 222.00 1 292.0 2.1 SMA

6AJ200A 6AJ200CA 600 200.0 1 224.00 247.00 1 324.0 1.9 SMA

Buscar materiales alternativos

The brand LEIDITECH offers ESD part numbers such as ESD0521C, which can replace ST's ESDALC6V1-1BU2.

The brand LEIDITECH offers ESD part numbers such as ESD0521C, which can replace ST's ESDALC6V1-1U2.

The brand LEIDITECH offers ESD part numbers such as ESD9D5V, which can replace ST's ESDALC6V1-1M2.

The brand LEIDITECH offers ESD part numbers such as ESDA0504T5, which can replace ST's ESDALC6V1M3.

The brand LEIDITECH offers ESD part numbers such as ESDA0504T5, which can replace ST's ESDALC6V1P3.

The brand LEIDITECH offers ESD part numbers such as ESDA0504T5, which can replace ST's ESDALC6V1P5.

The brand LEIDITECH offers ESD part numbers such as ESDA0504T5, which can replace ST's ESDALC6V1P6.

The brand LEIDITECH offers ESD part numbers such as ESDA0504T5, which can replace ST's ESDALC6V1W5.

The brand LEIDITECH offers ESD part numbers such as SDA0505T6, which can replace ST's ESDA6V1-5P6.

The brand LEIDITECH offers ESD part numbers such as SDA05CW, which can replace ST's ESDA6V1-5W6.

The brand LEIDITECH offers ESD part numbers such as SDA05CW, which can replace ST's ESDALC6V1-5M6.

The brand LEIDITECH offers ESD part numbers such as SDA0505T6, which can replace ST's ESDALC6V1-5P6.

The brand LEIDITECH offers ESD part numbers such as SDA05W5, which can replace ST's ESDA5V3SC5.

The brand LEIDITECH offers ESD part numbers such as SDA05W5, which can replace ST's ESDA5V3SC6.

The brand LEIDITECH offers ESD part numbers such as SDA05W5, which can replace ST's ESDA6V1M6.

The brand LEIDITECH offers ESD part numbers such as SDA05W5, which can replace ST's ESDA6V1P6.

The brand LEIDITECH offers ESD part numbers such as SDA05W5, which can replace ST's ESDA6V1SC5.

The brand LEIDITECH offers ESD part numbers such as SDA05W5, which can replace ST's ESDA6V1SC6.

The brand LEIDITECH offers ESD part numbers such as SDA05W5, which can replace ST's ESDA6V1W5.

The brand LEIDITECH offers ESD part numbers such as SDA1511CDN, which can replace ST's ESDA14V2-1BF3.

The brand LEIDITECH offers ESD part numbers such as SDA2411CDN, which can replace ST's ESDALC20-1BF4. The brand LEIDITECH of offers the ESD part number SM05, which can replace the ST's ESDAVLC6V1-1BT2.

The brand LEIDITECH of offers the ESD part number ULC0511CDN30, which can replace the ST's ESDAXLC4-1BF3.

The brand LEIDITECH of offers the ESD part number ULC0511CDN30, which can replace the ST's ESDAXLC6-1BT2.

The brand LEIDITECH of offers the ESD part number ULC0511CDN30, which can replace the ST's ESDAXLC6-1BT2Y.

The brand LEIDITECH of offers the ESD part number ULC0511CDN30, which can replace the ST's ESDAXLC6-1MY2.

The brand LEIDITECH of offers the ESD part number ULC0721C, which can replace the ST's ESDARF02-1BU2.

The brand LEIDITECH of offers the ESD part number ULC0721C, which can replace the ST's ESDARF02-1BU2CK.

The brand LEIDITECH of offers the ESD part number SAT100H200T, which can replace the ST's STPS40170C.

The brand LEIDITECH of offers the ESD part number SAT60TL45CPT, which can replace the ST's STPS60L30CW.

The brand LEIDITECH of offers the ESD part number SLT40L60FCT, which can replace the ST's STPS30L60CT.
